Dwyer V7-WBS-30N
SKU: CS3040030MPN: V7-WBS-30NAlternate Part #: 119170-10
V7-WBS-30N BR 1 NPT TRIM VN
$144.03
UnitAvailable on backorder
Product Details
Flotect® vane operated flow switch, weatherproof, brass body, 1” NPT, trimmable vane.
Attributes
| Agency Approval | CE, UL. |
| Commodity Code | 8213 |
| Conduit Connection | ½” NPSM. |
| Electrical Connection | 3 screw type, common, normally open and normally closed. |
| Electrical Rating | 10 A @ 125, 250, 480 VAC; ⅛ hp @ 125 VAC, ¼ hp @ 250 VAC. |
| Enclosure Rating | Weatherproof, meets NEMA 4X (IP66). |
| Mounting Orientation | Horizontal or vertical (actuation flow rates are based on horizontal pipe runs in the vertical position). Will not work in vertical pipe with down flow. |
| Pipe Size | 1” to 4”. |
| Pressure Limit | 250 psi (17.2 bar). |
| Process Connection | 1” male NPT. Contact factory for optional tees. |
| Service | Liquids compatible with wetted materials that are non-coating and noncrystallizing. |
| Set Point Adjustment | Vane is trimmable, see set point chart on Catalog page. |
| Switch Type | SPDT snap switch. |
| Upper Body Material | Die cast aluminum. |
| Wetted Material | Vane: 301 SS, Process connection: Brass or 316 SS, Magnet: Ceramic, Other: 301, 302 SS. |
Specifications
| SKU | CS3040030 |
|---|---|
| MPN | V7-WBS-30N |
| Alternate Part # | 119170-10 |
