Square D XCKL106

Name: Square D XCKL106
Brand: Square D
SKU: CS3007880
Availability: OutOfStock

SKU: CS3007880MPN: XCKL106

Limit switch, Limit switches XC Standard, XCKL, cats whisker, 1NC+1 NO, snap action, Cable gland

Product Details

Limit Switch XCKL - Cats Whisker - 1NC+1NO - Snap Action - Cable Gland

Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Body Material	zamak
Body Type	fixed
Contact Operation	snap action
Contacts Insulation Form	Zb
Contacts Type And Composition	1 NC + 1 NO
Device Short Name	XCKL
Fixing Mode	by the body
Head Type	multi-directional head
Material	metal
Mechanical Durability	10000000 cycles
Minimum Actuation Speed	0.01 m/min
Minimum Torque For Tripping	0.13 N.m
Movement Of Operating Head	multi-directional
Number Of Poles	2.0
Positive Opening	without
Product Certifications	CSA# #UL
Product Or Component Type	limit switch
Protective Treatment	TC
Range Of Product	Telemecanique Limit switches XC Standard
Series Name	standard format
Standards	IEC 60204-1# #UL 508# #IEC 60947-5-1# #EN 60947-5-1# #CSA C22.2 No 14# #EN 60204-1
Switch Actuation	by any moving part
Terminals Description Iso N 1	(21-22)NC# #(13-14)NO
