Eaton E50SBL
SKU: CS249262MPN: E50SBLUPC/EAN: 782113775371
Eaton E50 NEMA heavy duty plug-in limit switch
Contact us for pricing and availability
Product Details
Eaton E50 NEMA heavy duty plug-in limit switch,10A at 12 Vac,1A at 125 Vdc,2NO-2NC,Die cast zinc,NEMA 1,3,3S,4,4X,6,6P,13,IP67,LED indicator,24-120 Vac/dc,10A,1A,Two-pole,-40° to 250°F (-40° to 121°C),E50 Heavy Duty Plug In
Attributes
| Contact Configuration | 2 NO-2 NC |
| Contact Rating | 10A at 12 Vac, 1A at 125 Vdc |
| Enclosure Material | Die cast zinc |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67 |
| Led Indicator | LED indicator |
| Light Unit Voltage | 24-120 Vac/dc |
| Maximum Ac Current | 10 A |
| Maximum Dc Current | 1 A |
| Number Of Poles | Two-pole |
| Operating Temperature Max | 250 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -40 FAH |
| Operating Temperature Min Uom | FAH |
| Series | E50 heavy duty plug in |
Specifications
| SKU | CS249262 |
|---|---|
| MPN | E50SBL |
| UPC/EAN | 782113775371 |
