All ProductsTurck

Turck NI30-Q130-ADZ30X2

SKU: CS192969MPN: NI30-Q130-ADZ30X2Alternate Part #: 42095UPC/EAN: 4047101092806

42095 - FERRITE, RECT., AC, CABLE

Turck NI30-Q130-ADZ30X2, NI30-Q130-VN4X2, NI30-Q130-VP4X2, NI30-Q130-VP4X2-0.2-RS4.4T
$803.72
Unit
Available on backorder
remove
add

Product Details

Inductive Sensor

  • Rectangular, height 48 mm
  • Active face in front
  • Plastic, PBT
  • AC 2-wire, 20…250 VAC
  • DC 2-wire, 10…300 VDC
  • NO contact
  • Cable connection

Attributes

Ambient Temperature -25…+70 °C
Construction Size 130 x 57 x 48 mm, Q130
Customs Tariff Number 85365080900.0000
Design Rectangular
Ecl Ss Code V5 1 4 27270101 -/- Inductive proximity switch
Electrical Connection Cable
Housing Material Plastic, PBT
Mounting Non-flush
Operating Voltage 20…250 VAC / 10…300 VDC
Output Function NO contact, 2-wire
Protection Class IP67
Rated Switching Distance 30 mm
Switching Frequency 0.020 kHz

Specifications

SKUCS192969
MPNNI30-Q130-ADZ30X2
Alternate Part #42095
UPC/EAN4047101092806
