Square D XX930A3A2M12

Name: Square D XX930A3A2M12
Brand: Square D
SKU: CS1688366
Availability: OutOfStock

SKU: CS1688366MPN: XX930A3A2M12

Ultrasonic sensors XX, ultrasonic sensor cylindrical M30, Sn 8 m, M12 connector

Product Details

Ultrasonic sensor cylindrical M30 - Sn 8 m - M12 connector

Sd Sensing Range	0.3-8 m
Ambient Air Temperature For Operation	-20-60 °C
Ambient Air Temperature For Operation 1	-20-60 °C
Ambient Air Temperature For Storage	-40-80 °C
Analogue Output Function	4…20 mA
Beam Angle	16 °
Blind Zone	0-300 mm
Blind Zone 1	0-300 mm
Current Consumption	60 mA
Deviation Angle From 90 Of Object To Be Detected	-5-5 °
Enclosure Material	ULTEM
Front Material	epoxy
Function Available	without synchronisation mode
Marking	CE
Marking 1	CE
Material	plastic
Maximum Delay First Up	1200 ms
Maximum Delay Recovery	250 ms
Maximum Delay Response	250 ms
Product Certifications	UL# #cCSAus
Range Of Product	Telemecanique Ultrasonic sensors XX
Sensor Design	cylindrical M30
Sensor Name	XX9
Sensor Type	ultrasonic sensor
Series Name	general purpose
Setting Up	slope selection using teach button
Standards	IEC 60947-5-2
Thread Type	M30 x 1.5
Transmission Frequency	75 kHz
Type Of Output Signal	analogue
Wiring Technique	4-wire
