Square D VM18NNOQ

Name: Square D VM18NNOQ
Brand: Square D
SKU: CS1688517
Availability: InStock

SKU: CS1688517MPN: VM18NNOQUPC/EAN: 785901532125

Hyde Park, ultrasonic sensor cylindrical M18, Sn508mm, NO, 12...24 VDC, M12

7 in stock

Product Details

Hyde Park Ultrasonic sensor cylindrical M18 - Sn508mm - NO - 12..24VDC - M12

Sd Sensing Range	50.8-508 mm
Ambient Air Temperature For Operation	-30-70 °C
Ambient Air Temperature For Operation 1	-30-70 °C
Ambient Air Temperature For Storage	-40-85 °C
Beam Angle	5 °
Blind Zone	0-51 mm
Blind Zone 1	0-51 mm
Current Consumption	40 mA
Device Short Name	VM18
Discrete Output Function	1 NO
Discrete Output Type	NPN
Enclosure Material	PBT
Front Material	glass epoxy
Iso Thread	M18 x 1
Marking	CE
Marking 1	CE
Material	plastic
Product Certifications	UL
Product Specific Application	-
Range Of Product	Hyde Park
Sensor Design	cylindrical M18
Sensor Type	ultrasonic sensor
Series Name	Virtu VM18
Standards	EN 60947
Transmission Frequency	300 kHz
Type Of Output Signal	discrete
Type Of Sensing Window	adjustable
Wiring Technique	4-wire
