Square D 9007CR53B2

Name: Square D 9007CR53B2
Brand: Square D
SKU: CS1656440
Price: 269.68 USD
Availability: InStock

SKU: CS1656440MPN: 9007CR53B2UPC/EAN: 785901763352

Limit switch, 9007, 600 V 10amp c +options

$269.68

Unit

1 in stock

Quantity

remove

add

Product Details

9007CR Limit Switch - 1 NO/NC - Rotary Head - CW+CCW - Standard

Ithe Conventional Enclosed Thermal Current	0.417
Ambient Air Temperature For Storage	-20-185 °F
Body Material	aluminium
Body Type	fixed
Contact Form	Form Z
Contact Operation	snap action
Contacts Material	silver contacts
Contacts Type And Composition	NC-NO
Device Short Name	9007CR
Electrical Durability	1000000 cycles
Environmental Characteristic	standard environment
Fixing Mode	by the body
Function Available	-
Head Material	zinc
Head Type	rotary head
Level Or Class	Class I Division 1 Groups B/C/D# #Class II Division 1 Groups E/F/G
Material	metal
Maximum Displacement Angle	90 °
Mechanical Durability	10000000 cycles
Minimum Torque For Tripping	4 lbf.in
Movement Of Operating Head	rotary
Number Of Poles	1
Positive Opening	without
Product Or Component Type	limit switch
Product Specific Application	hazardous location box
Protective Treatment	epoxy powder coat
Range Of Product	9007
Sale Per Indivisible Quantity	1.0000
Series Name	heavy duty
Switch Actuation	CW and CCW# #from left and right
Switch Function	SPDT-DB
Terminals Description Iso N 1	(3-4)NO# #(1-2)NC
