Square D XS8G12MA230

Name: Square D XS8G12MA230
Brand: Square D
SKU: CS1653775
Availability: OutOfStock

SKU: CS1653775MPN: XS8G12MA230

Inductive proximity sensors XS, inductive sensor XS8 12x40x26, plastic, Sn4mm, 24...240VAC/DC, cable 2 m

Product Details

Inductive Sensor,264V, 200ma, xs, XS8 12x40x26 - plastic - Sn4mm - 24..240VAC/DC - cable 2m

Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-85 °C
Body Type	fixed
Cable Composition	2 x 0.34 mm²
Detection Face	lateral
Detector Flush Mounting Acceptance	non flush mountable
Differential Travel	3…20% of Sr
Discrete Output Function	1 NO
Enclosure Material	plastic
Front Material	plastic
Marking	CE
Marking 1	CE
Material	plastic
Maximum Delay First Up	40 ms
Maximum Delay Recovery	2 ms
Maximum Delay Response	1 ms
Operating Zone	0-3.2 mm
Output Circuit Type	AC/DC
Product Certifications	UL# #CCC# #CSA
Product Specific Application	-
Range Of Product	Telemecanique Inductive proximity sensors XS
Repeat Accuracy	<= 10% of Sr
Repeat Accuracy 1	<= 10% of Sr
Sensor Design	form 12 x 40 x 26
Sensor Name	XS8
Sensor Type	inductive proximity sensor
Series Name	general purpose
Size	26 mm
Type Of Output Signal	discrete
Wire Insulation Material	PVC
Wiring Technique	2-wire
