Square D XS8E1A1PBL01M12

Name: Square D XS8E1A1PBL01M12
Brand: Square D
SKU: CS4814125
Availability: OutOfStock

SKU: CS4814125MPN: XS8E1A1PBL01M12

Inductive proximity sensors XS, inductive sensor XS8 26x26x13, PBT, Sn15mm, 12...24 VDC, M12 0.15 m

Product Details

OsiSense XS Inductive Sensor

Sensor Design: Flat form 26 x 26 x 13* Enclosure Material: PBT* Size 13mm* 12-24V DC* Discrete Output Function: 1 NC* Degree of Protection: IP67 Double Insulation Confirming to IEC 60529

Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-85 °C
Body Type	fixed
Detection Face	frontal
Detector Flush Mounting Acceptance	non flush mountable
Device Application	-
Differential Travel	1…15% of Sr
Discrete Output Function	1 NC
Discrete Output Type	PNP
Enclosure Material	PBT
Front Material	PBT
Marking	CE
Marking 1	CE
Material	plastic
Maximum Delay First Up	10 ms
Maximum Delay Recovery	0.8 ms
Maximum Delay Response	0.3 ms
Output Circuit Type	DC
Product Certifications	Ecolab# #CSA# #UL
Range Of Product	Telemecanique Inductive proximity sensors XS
Sensor Design	flat form 26 x 26 x 13
Sensor Name	XS8
Sensor Type	inductive proximity sensor
Series Name	general purpose
Size	13 mm
Type Of Output Signal	discrete
Wire Insulation Material	PvR
Wiring Technique	3-wire
