Square D XS8D1A1PAM12

Name: Square D XS8D1A1PAM12
Brand: Square D
SKU: CS1674178
Availability: OutOfStock

SKU: CS1674178MPN: XS8D1A1PAM12

Inductive proximity sensors XS, inductive sensor XS8 80x80x26, PBT, Sn60mm, 12...24 VDC, M12

Product Details

PROXIMITY SENSOR SZ D DC PNP XS8

Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-85 °C
Body Type	fixed
Detection Face	frontal
Detector Flush Mounting Acceptance	non flush mountable
Device Application	-
Differential Travel	1…15% of Sr
Discrete Output Function	1 NO
Discrete Output Type	PNP
Enclosure Material	PBT
Front Material	PBT
Marking	CE
Marking 1	CE
Material	plastic
Maximum Delay First Up	10 ms
Maximum Delay Recovery	6 ms
Maximum Delay Response	0.3 ms
Output Circuit Type	DC
Product Certifications	CSA# #UL# #Ecolab
Range Of Product	Telemecanique Inductive proximity sensors XS
Sensor Design	flat form 80 x 80 x 26
Sensor Name	XS8
Sensor Type	inductive proximity sensor
Series Name	general purpose
Size	26 mm
Type Of Output Signal	discrete
Wiring Technique	3-wire
