Schneider Electric 9037HG34Z20

Name: Schneider Electric 9037HG34Z20
Brand: Schneider Electric
SKU: CS1652315
Availability: OutOfStock

SKU: CS1652315MPN: 9037HG34Z20Alternate Part #: SENA-9037HG34Z20UPC/EAN: 785901328124

Float switch, Pumptrol, closed tank, NEMA 1, screw in bushing, 2 NC DPST DB contacts

Product Details

FLOAT SWITCH 575V 1HP

Ambient Air Temperature For Operation	-22-220 °F
Ambient Air Temperature For Operation 1	-22-220 °F
Ambient Air Temperature For Storage	-22-220 °F
Device Application	closed tank
Device Mounting	screw-in bushing
Device Short Name	9037H
Electrical Circuit Type	power circuit
Enclosure Material	polypropylene or equivalent
Factory Modification	without
Float Position	left
Float Rod Angle	45°
Kit Composition	float# #rod# #float switch
Local Signalling	with external pointer
Materials In Contact With Fluid	yellow brass# #stainless steel 316# #cast iron# #stainlesss steel 304# #viton
Maximum Operating Rate	60 cyc/mn
Mechanical Durability	300 cycles
Operating Position	vertical position only
Product Certifications	UL listed file E12158# #CSA file LR25490
Product Destination	for closed tank
Product Or Component Type	float switch
Product Specific Application	liquid level control
Quantity Per Set	set of 1
Range Of Product	Square D Pumptrol
Standards	CE# #UL 508
Terminal Block Type	4 terminals
Terminals Description Iso N 1	line-load-load-line
Type Of Packing	individual
