Veris H800
SKU: CS144560MPN: H800Alternate Part #: VER-H800
Current Switch: Fixed Trip Point, 0.25-200 Amp, Normally Open 1.0A@30VAC/DC Status Output, 0.25A or less Fixed Trip Point, Mini Solid-Core Housing
$17.53
Unit2 in stock
Product Details
Current Switch:
- Fixed Trip Point* 0.25-200 Amperage Range* Normally Open 1.0A@30VAC/DC Status Output* 0.25A or less Fixed Trip Point* Mini Solid-Core Housing* UL Listed for us on 75 deg. C insulated conductors
Attributes
| Sena Ambient Air Temperature For Operation | -40-50 °C |
| Sena Ambient Air Temperature For Operation 1 | -40-50 °C |
| Sena Ambient Air Temperature For Operation 2 | -40-50 °C |
| Sena Awg Gauge | AWG 24…AWG 14 |
| Sena Awg Gauge 1 | AWG 24…AWG 14 |
| Sena Current Measurement Range | 0.25…200 A |
| Sena Device Application | building automation systems |
| Sena Mounting Support | solid core housing |
| Sena Network Frequency | 50…60 Hz |
| Sena Opening Diameter | 18 mm |
| Sena Output Current | 1 A at 30 V AC/DC |
| Sena Output Current 1 | 1 A at 30 V AC/DC |
| Sena Output Current 2 | 1 A at 30 V AC/DC |
| Sena Product Certifications | UL# #CE |
| Sena Product Certifications 1 | UL# #CE |
| Sena Product Or Component Type | sensor |
| Sena Range Of Product | HX00 Series |
| Sena Relative Humidity | 10-90 % RH, non-condensing |
| Sena Relative Humidity 1 | 10-90 % RH, non-condensing |
| Sena Sensor Type | current switch, AC |
| Sena Sensor Type 1 | current switch, AC |
| Sena Type Of Measurement | AC current |
Specifications
| SKU | CS144560 |
|---|---|
| MPN | H800 |
| Alternate Part # | VER-H800 |
