Square D ZB4BP4

Name: Square D ZB4BP4
Brand: Square D
SKU: CS1125204
Price: 26.02 USD
Availability: OutOfStock

SKU: CS1125204MPN: ZB4BP4

Head for non illuminated push button, Harmony XB4, metal, projecting, red, 22mm, spring return, booted, unmarked

$26.02

Unit

Available on backorder

Quantity

remove

add

Product Details

Push button head, metal, projecting, red, Dia 22, spring return, booted, unmarked

Ambient Air Temperature For Operation	-40-70 °C
Ambient Air Temperature For Operation 1	-40-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Bezel Material	chromium plated metal
Device Presentation	basic element
Device Short Name	ZB4
Head Type	standard
Mechanical Durability	10000000 cycles
Mounting Diameter	22 mm
Operator Additional Information	clear boot
Product Certifications	BV# #GL# #UL listed# #CSA# #LROS (Lloyds register of shipping)# #DNV
Product Or Component Type	head for non-illuminated push-button
Protective Treatment	TH
Range Of Product	Harmony XB4
Sale Per Indivisible Quantity	1.0000
Shape Of Signaling Unit Head	round
Standards	UL 508# #EN/IEC 60947-5-4# #EN/IEC 60947-5-1# #EN/IEC 60947-1# #EN/IEC 60947-5-5# #JIS C8201-5-1# #CSA C22.2 No 14# #JIS C8201-1
