HVAC/RActuatorsSiemens Building Technologies

Siemens GEB131.1U

Name: Siemens GEB131.1U
Brand: Siemens Building Technologies
SKU: CS793609
Availability: OutOfStock

SKU: CS793609MPN: GEB131.1UUPC/EAN: 4034106331306

Electric Actuator 132 in.-lb. Floating

Siemens Building Technologies GEB131.1U, GEB161.1U

Discontinued - Contact Us For Pricing & Availability

Product Details

Floating Actuator Direct-Coupled Nonspring-Return Shaft Type Self-Centering Torque (In.-Lbs.) 132 Stroke Deg 90 Height (In.) 2-⅝ Width (In.) 8-⅜ Depth (In.) 3-¼ 3 Ft 18 AWG Lead Floating -25 to +130 3 VA Timing (Sec.) 125 Voltage 24 Includes Mounting Bracket Screws and Hex Key

Attributes

Max Temp	130 °F
NSR/SR Actuator	Non-Spring Return
Actuator Type	Electronic
Fail-safe Position	Fail-In-Place
Control Signal Type	Floating control/2-position
Nominal Voltage	24 VAC
NEMA Rating	NEMA 1, die-cast aluminum alloy enclosure, IP54 according to EN 60 529
Damper Actuator Torque	132 lb-in
Plenum Rating	Standard
Damper Actuation Application	Control Damper
Cable Length	3 ft
Damper Actuation Style	Rotary
Stroke Degrees	90 °
Power Consumption	3 VA / 3 W
Watts	3
VA Rating	3
Color	Aluminum metallic
