ACI ASENSE MIII WALL

Name: ACI ASENSE MIII WALL
Brand: ACI
SKU: CS6287842
Availability: OutOfStock

SKU: CS6287842MPN: ASENSE MIII WALLAlternate Part #: 137435

CO2/CO WALL MOUNT SNSR, W/DISP

Product Details

CO2/CO WALL MOUNT SNSR, W/DISP

Product Family Specifications

Display	4 digits, 7 segments LCD with ppm indicator
Accuracy	CO2: ±30ppm ±3% of reading Note: CO2 Accuracy is defined after minimum three (3) ABC periods (1 period \= 8 days) of continuous operation CO: Standard Range: ±10ppm \| Extended Range: ±20% of reading
Gas Types	Carbon dioxide (CO2) \& Carbon monoxide (CO)
Warm Up Time	≤15min (more when un-powered for a long time)
Sensing Range	CO2: 0 to 2000 ppm CO: Standard Range: 0–100 ppm \| Extended Range: 101–500ppm
Output Signals	Output 1 (CO): 0/2 to 10V, 0/4 to 20 mA, 0 to 100 ppm Output 2 (CO2): 0/2 to 10V, 0/4 to 20 mA, 0 to 2000 ppm Output 3(Relay): Closed: (CO \< 30ppm) AND (CO2 \< 1400ppm); Open: (CO > 35ppm) OR (CO2 > 1500ppm) Output 4(Open Collector): Error detection
Product Weight	0.812 lbs. (0.368 kg)
Sensing Method	CO2: Single beam Non-dispersive Infrared (NDIR) CO: Electrochemical gas sensor with compensation for temperature variations
Supply Current	3W
Supply Voltage	24 VAC/VDC ±20%; 50/60Hz (Half-wave rectified)
Life Expectancy	>5 years
Agency Approvals	EMC Directive 2014/30/EC, RoHS Directive 2011/65/EU \& RoHS 3 Directive 2015/863/EU
Enclosure Rating	Box: IP65 rated, PC \& ABS blend, Flammability Rating UL94V-0 Cover: Makrolon® 6555 plastic, Flammability Rating UL94V-0 Pipe (Duct Only): PC \& ABS blend, Flammability Rating UL94V-0
Self-Diagnostics	Complete function check, yellow LED; LCD error indication
Product Dimensions	Wall Mount: (H) 5.59” (142 mm) x (W) 3.31” (84 mm) x (D) 1.81” (46 mm) Duct Probe: (L) 9.65” (245 mm) x (D) 1.57” (40mm)
Datalogging Storage	Internal data logger of CO- and CO2 readings, 2 X 960 samples, corresponding to just under two weeks data sampling of CO- and CO2 values in 20 minutes intervals
Extended CO2 Ranges	Up to 10,000 ppm (factory set or programming cable required)
Output Load Impedance	0/4-20 mA: 500 Ohms maximum \| 0/2-10 VDC: 5K Ohms Minimum
Operating Temperature / RH	32 to 122ºF (0 to 50ºC) \| 5 to 95% RH, non-condensing
Storage Temperature \| RH Range	32 to 122ºF (0 to 50ºC) \| 5 to 95% RH, non-condensing
Relays / Contact Type / Relay Contact Ratings	SPST – NC \| 1mA/5V to 1A/50VAC/24VDC
