ACI TTL-232R-3V3

Name: ACI TTL-232R-3V3
Brand: ACI
SKU: CS6287437
Availability: OutOfStock

SKU: CS6287437MPN: TTL-232R-3V3Alternate Part #: 134207

ASENSE CO2 USB CAL CABLE

Product Details

ASENSE CO2 USB CAL CABLE

Product Configuration

Gas Type	None

Product Family Specifications

Accuracy	CO21: ±30 ppm and ±3% of reading Note: Accuracy is defined after minimum three (3) ABC periods (1 period \= 8 days) of continuous operations Temperature: ±1.8ºF (1ºC)
Mounting	4-6’ off the floor
Calibration	Senseair ABC algorithm (Automatic Baseline Correction) Note: Building CO2 levels must drop to 400 ppm some time during the week for ABC to work properly \| If the building is occupied 24 hrs/day, ABC must be turned off \| Changes can be made using TTL-232R-3V3 cable and UIP5 software
Sensor Life	>15 years In normal Indoor Air Quality (IAQ) applications \| Corrosive environments are excluded
Warm Up Time	\<5 minutes (@ full specs 15 minutes)
Coverage Area	7500 sq. ft. maximum
Repeatability	±20 ppm ±1% of measured value
Sensing Range	CO2: 0 to 2000 ppm Temperature: -4 to 140ºF (-20 to 60ºC)
Output Signals	Out 1 (CO2): 0/2 to 10V, 0/4 to 20 mA, 0 to 2000 ppm Out 2 (Temperature): 0/2 to 10V, 0/4 to 20 mA, 32 to 122ºF (0 to 50ºC)
Product Weight	ASENSE-R: 0.300 lbs (0.136 kg) \| ASENSE-R-LCD: 0.314 lbs (0.142 kg)
Sensing Method	Single beam Non-dispersive Infrared (NDIR)
Supply Voltage	24 VAC/VDC ±20%; 50/60 Hz, 10.5 to 40 VDC maximum (Half-wave rectified)
Agency Approvals	CE
Relay (Optional)	Out 3: N.O. or N.C. rated 0.5A @ 125 VAC; 1A @ 24 VDC
Relay Durability	Mechanical: 5,000,000 operations minimum (at 36,000 operations/hr) Electrical: 100,000 operations minimum (under rated load, at 1,800 operations/hr)
Relay Trip Point	1000 ppm (factory set)
Self-Diagnostics	Complete function check, yellow LED; LCD error indication (display model only)
Annual Zero Drift	\<± 0.3% of measurement range
Power Consumption	\<1W
Display (Optional)	4 digits, 7 segments LCD with ppm indicator
Enclosure Material	ABS, Flammability Rating UL94-HB
Operating Pressure	+1.6% per 0.145 psi (1 kPa) deviation from normal pressure \| (1 Atmosphere \= 14.7 psi (1.013 KPa))
Operating RH Range	0 to 85% RH Non-condensing
Product Dimensions	ASENSE-R \& ASENSE-R-LCD: (H) 5.12” (130 mm) x (W) 3.35” (85.1 mm) x (D) 1.18” (30 mm)
Wiring Connections	0.00232 in² (1.5 mm²) screw terminals
Extended CO2 Ranges	2000 to 10,000 ppm (factory set or programming cable required)
Response Time (T1/e)	\<10 seconds @ 30 cc / minimum flow rate, \<3 minutes diffusion time
Operating Environment	Residential, commercial, and industrial spaces
Relay Deadband/Hysteresis	100 ppm (factory set)
Storage Temperature Range	Standard Versions: -40 to 158ºF (-40 to 70ºC LCD Versions: -4 to 122ºF (-20 to 50ºC) 0 to 85% RH Non-condensing
Operating Temperature Range	32ºF to 122ºF (0ºC to 50ºC)
Extended Range Accuracy>2,000 PPM	+/- 30 ppm and +/- 5% of reading
