ACI MOD9200LON-A

Name: ACI MOD9200LON-A
Brand: ACI
SKU: CS6287078
Availability: OutOfStock

SKU: CS6287078MPN: MOD9200LON-AAlternate Part #: 131048

Wireless, LonWorks Network Transceiver, 30 Temp, 6 RH Sensors Inputs (Max)

Product Details

Wireless, LonWorks Network Transceiver, 30 Temp, 6 RH Sensors Inputs (Max)

Product Configuration

Enclosure	Plastic

Product Family Specifications

Wire Size	16 AWG (1.31 mm²) to 26 AWG (0.129 mm²)
Connections	Screw Terminal Blocks
Data Protocol	IEEE 802.15.4-2003/2006
Product Weight	2.20 lbs (1.00 kg)
Supply Current	0.5A Nominal
Supply Voltage	24 VAC, 60Hz (Full wave rectified)
Communication Wire	Eschelon approved 22 AWG wire
Operating RH Range	30 to 50% RH, Noncondensing
Product Dimensions	(L) 8.78” (223.01 mm) x (W) 4.72” (119.89 mm) x (H) 2.36“ (59.94 mm)
RF Characteristics	900 MHz, Operating Frequency 10 channels between 902 – 928 MHz Transmitter Power: 11 dBm \| Receiver Sensitivity: -11 dBm
System Requirements	• PC (Notebook or Laptop) with Windows 98, XP, Vista, Windows 7, or Windows 10, Ethernet port, and 10 GB of hard drive memory, direct connection from PC to MOD9200LON: RJ45 Crossover Cable (not provided by ACI) • IP Address of PC must have static address of 192.168.0.2 or above
Transmission Distance	200 – 300 ft horizontally depending on building type and constructions, and typically one floor above and below the transceiver vertically
Configuration Software	Included; Data registers need to be configured prior to use
LonWorks® Protocols 1	Temperature: SNVT_temp_p \| Override Push Button: SNVT_occupancy Setpoint Adjustment: SNVT_temp_p \| Humidity: SNVT_lev_percent Sensor Status/Alarms: SNVT_count PPM: SNVT_ppm The MOD9200LON Transceiver is pre-defined with fixed configurations
Storage Temperature Range	-4 to 176ºF (-20 to 80ºC)
Operating Temperature Range	32 to 122ºF (0 to 50ºC)
Physical Network Connection	FTT-10 (Free Topology Twisted Pair)
Terminal Block Torque Rating	0.37 ft-lb (0.5 Nm) Nominal
Enclosure Material \| Flammability Rating	ABS Plastic \| UL94-5VA
