ACI EX2432D

Name: ACI EX2432D
Brand: ACI
SKU: CS6287033
Availability: OutOfStock

SKU: CS6287033MPN: EX2432DAlternate Part #: 130696

Wireless, Sensor Receiver, Expansion Module, 4 Digital \& 4 Analog Outputs

ACI EX2432D, MOD9200BNT, RT2630A-AC, RT2630B-AC

Product Details

Wireless, Sensor Receiver, Expansion Module, 4 Digital \& 4 Analog Outputs

Product Family Specifications

Wire Size	16 AWG (1.31 mm2) to 26 AWG (0.129 mm2)
Connections	Screw Terminal Blocks
Data Protocol	IEEE 802.15.4-2003/2006
Analog Outputs	Four (4), 0-5/10V jumper selectable
Product Weight	Standard: 1.67 lbs (0.76 kg) \| NEMA 4X: 2.13 lbs (0.97 kg)
Supply Current	300 mA
Supply Voltage	24 VAC, 60 Hz (Full wave rectified) Supplied from RM2432D
Relay Durability	Mechanical: 5,000,000 operations minimum @ 36K operations/hr Electrical: 100,000 operations minimum (under rated load @ 1.8K operations/hr)
Lost Signal Alarm	One (1) SPDT, Dry contact relay, 1.0A, 30 VDC @ 104ºF (40ºC), 0.5A, 125 VAC @ 104ºF (40ºC) Resistive
Product Dimensions	Standard: (L) 8.78” (223.01 mm) x (W) 4.72” (119.89 mm) x (H) 2.36“ (59.94 mm) NEMA 4X: (L) 8.74” (222.00 mm) x (W) 5.74” (145.80 mm) x (H) 2.96” (75.18 mm)
RF Characteristics	900 MHz, Operating Frequency 10 channels between 902 – 928 MHz Transmitter Power: 11 dBm \| Receiver Sensitivity: -11 dBm
Digital Output Type	Four (4) SPDT Pilot Duty Relays, Dry Contact
Contact (Load) Rating	1.0A, 30 VDC @ 104ºF (40ºC), 0.5A, 125 VAC @ 104ºF (40ºC) Resistive
Transmission Distance	200 – 300 ft horizontally depending on building type and constructions, and typically one floor above and below the transceiver vertically
Configuration Software	• Laptop with Windows 98, XP, Vista, Windows 7 or Windows 10, Ethernet port, and 10GB memory • Direct connection from PC to RM2432D using CK2432D serial to RJ11 programming cable (USB to serial adapter not provided by ACI) • IP Address of PC must have static address of 192.168.0.2 or above
Operating Humidity Range	30 to 50% RH, Noncondensing
Storage Temperature Range	-4 to 176ºF (-20 to 80ºC), 70% RH
Operating Temperature Range	32 to 122ºF (0 to 50ºC)
Terminal Block Torque Rating	0.37 ft-lb (0.5 Nm) Nominal
Enclosure Material \| Flammability Rating	Standard: ABS Plastic \| UL94-5VA \| NEMA 4X: Polycarbonate Plastic \| UL94 HB
