Carrier ZR144KCE-TFE-950

Name: Carrier ZR144KCE-TFE-950
Brand: Carrier
SKU: CS5793863
Availability: OutOfStock

SKU: CS5793863MPN: ZR144KCE-TFE-950

COPELAND COMPR SCROLL 57

Product Details

COPELAND COMPR SCROLL 57

Amps	13.1
Phase	Three
Voltage	575 VAC
Oil Type	Polyolester (POE)
UL Listed	Yes
BTU Output	122,500
Protection	Internal Inherent Protection
Cycle/Hertz	60 Hz
Refrigerant	R-134a; R-22; R-407C
Displacement	11.65 (in^3/Rev)
Compressor Type	Scroll
Sound Level (dBA)	80
Compressor Housing	Hermetic
Liquid Temperature	105°F to 115°F (40.56°C to 46.11°C)
Mass Flow (lbs/hr)	1715 lbs./hr.; 2070 lbs./hr.
Mounting Dimensions	7.5” x 7.5” x 21.75”
Rated Load Amps (RLA)	14.2
Substantial Commodity	Steel
Condensing Temperature	120°F to 130°F (48.89°C to 54.44°C)
Return Gas Temperature	65°F
Suction Line Size (OD)	1 ⅜”
Evaporating Temperature	35°F (1.67°C)
Locked Rotor Amps (LRA)	100
Oil Charge Initial (oz.)	110
Discharge Connection Type	Stub
Suction Line Fitting Type	Stub
Discharge Connection Size (OD)	⅞”
