Dwyer A4-5
SKU: CS5728498MPN: A4-5Alternate Part #: 124310-04
A4-5 PR SW 120-250 PSID INC
$403.08
UnitAvailable on backorder
Product Details
Differential pressure switch, ±32 psi (2.2 bar) repeatability, set point (increasing) 120-250 psid (8.3-17.2 bar), set point (decreasing) 35-120 psid (2.4-8.3 bar).
Attributes
| Agency Approval | CE. |
| Agency Approvals | CE. |
| Commodity Code | R2AF |
| Electrical Connection | 24 AWG X 12” (30.5 cm) wire leads. |
| Electrical Rating | AC: 3 VA, 0.25A @ 120 VAC; 5 VA, 0.25A @ 175 VDC. |
| Mounting Orientation | Any. |
| Pressure Limit | 2000 psid (138 bar). |
| Process Connection | ¼” female NPT. |
| Repeatability | See Ordering page. |
| Service | Compatible gases. |
| Set Point Adjustment | See Ordering page. |
| Switch Type | SPDT. |
| Wetted Material | Body, piston, and fittings: anodized aluminum; spring: steel. |
Specifications
| SKU | CS5728498 |
|---|---|
| MPN | A4-5 |
| Alternate Part # | 124310-04 |
