Dwyer A4-1

Name: Dwyer A4-1
Brand: Dwyer
SKU: CS1767554
Price: 322.47 USD
Availability: OutOfStock

SKU: CS1767554MPN: A4-1Alternate Part #: 124310-00

A4-1 PR SW 7-13 PSID INC

$322.47

Unit

Available on backorder

Quantity

remove

add

Product Details

Differential pressure switch, ±2 psi (.14 bar) repeatability, set point (increasing) 7-13 psid (.48-.89 bar), set point (decreasing) 2-7 psid (.14-.48 bar).

Attributes

Agency Approval	CE.
Agency Approvals	CE.
Commodity Code	R2AF
Electrical Connection	24 AWG X 12” (30.5 cm) wire leads.
Electrical Rating	AC: 3 VA, 0.25A @ 120 VAC; 5 VA, 0.25A @ 175 VDC.
Mounting Orientation	Any.
Pressure Limit	2000 psid (138 bar).
Process Connection	¼” female NPT.
Repeatability	See Ordering page.
Service	Compatible gases.
Set Point Adjustment	See Ordering page.
Switch Type	SPDT.
Wetted Material	Body, piston, and fittings: anodized aluminum; spring: steel.
