Square D XCSB703

Name: Square D XCSB703
Brand: Square D
SKU: CS518202
Availability: OutOfStock

SKU: CS518202MPN: XCSB703Alternate Part #: SQD-XCSB703

Safety switch, Telemecanique Safety switches XCS, metal XCSB, 2 NC + 1 NO, slow break, 1 entry tapped ½” NPT

Product Details

Metal safety switch XCSB, 2 NC + 1 NO, slow break, 1 entry tapped ½ IN NPT

Ithe Conventional Enclosed Thermal Current	0.417
Actuator Forcible Withdrawal Rtc	1500 N
Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Body Material	zamak
Component Name	XCSB
Contact Operation	slow-break, break before make
Contacts Type And Composition	2 NC + 1 NO
Design	industrial
Head Material	zamak
Head Type	key operated turret head
Locking Options Description	with locking of actuator, unlocking by push-button
Material	metal
Maximum Actuation Speed	0.5 m/s
Mechanical Durability	600000 cycles
Minimum Actuation Speed	0.01 m/s
Minimum Actuator Force For Extraction	20 N
Number Of Poles	3.0
Positive Opening	with NC contact
Product Certifications	UL# #CSA
Product Or Component Type	safety switch
Protective Treatment	TC
Range Of Product	Telemecanique Safety switches XCS
Standards	EN/IEC 60947-5-1# #CSA C22.2 No 14# #EN 1088/ISO 14119# #EN/ISO 12100# #UL 508# #EN/IEC 60204-1
