Square D XCSA803

Name: Square D XCSA803
Brand: Square D
SKU: CS1679299
Availability: OutOfStock

SKU: CS1679299MPN: XCSA803UPC/EAN: 3389110718935

Safety switch, Telemecanique Safety switches XCS, metal XCSA, 3 NC, slow break, 1 entry tapped ½” NPT

Product Details

Preventa Safety Switch

Material: Metal* Head Type: Key operated turret head* Contacts Type and Composition: 3 NC* Contact Operation: Slow-break, break before make* Electrical Connection: Terminal, 1x0.5 - 2x1.5mm with or without cable end* Number of Poles: 3-Poles* Local Signaling: Without* Conventional Enclosed Thermal Current: 10A* Degree of Protection: IP67

Ithe Conventional Enclosed Thermal Current	0.417
Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Body Material	zamak
Component Name	XCSA
Contact Operation	slow-break, simultaneous
Contacts Type And Composition	3 NC
Design	industrial
Head Material	zamak
Head Type	key operated turret head
Locking Options Description	without locking of actuator
Material	metal
Maximum Actuation Speed	0.5 m/s
Mechanical Durability	1000000 cycles
Minimum Actuation Speed	0.01 m/s
Minimum Actuator Force For Extraction	20 N
Number Of Poles	3.0
Positive Opening	with NC contact
Product Certifications	CSA# #UL
Product Or Component Type	safety switch
Protective Treatment	TC
Range Of Product	Telemecanique Safety switches XCS
Standards	UL 508# #EN/IEC 60947-5-1# #CSA C22.2 No 14# #EN/ISO 12100# #EN/IEC 60204-1# #EN 1088/ISO 14119
