Eaton 259768

Name: Eaton 259768
Brand: Eaton
SKU: CS5021056
Price: 349.46 USD
Availability: OutOfStock

SKU: CS5021056MPN: 259768UPC/EAN: 04015082597689

Eaton Moeller series NZM release

$349.46

Unit

Available on backorder

Quantity

remove

add

Product Details

Eaton Moeller series NZM - Molded Case Circuit Breaker. Shunt release (for power circuit breaker), 480-525VAC/DC

Attributes

10 10 Temperature Rise	The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
10 11 Short Circuit Rating	Is the panel builder’s responsibility. The specifications for the switchgear must be observed.
10 12 Electromagnetic Compatibility	Is the panel builder’s responsibility. The specifications for the switchgear must be observed.
10 13 Mechanical Function	The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
10 2 2 Corrosion Resistance	Meets the product standard’s requirements.
10 2 3 1 Verification Of Thermal Stability Of Enclosures	Meets the product standard’s requirements.
10 2 3 2 Verification Of Resistance Of Insulating Materials To Normal Heat	Meets the product standard’s requirements.
10 2 3 3 Resist Of Insul Mat To Abnormal Heat Fire By Internal Elect Effects	Meets the product standard’s requirements.
10 2 4 Resistance To Ultra Violet Uv Radiation	Meets the product standard’s requirements.
10 2 5 Lifting	Does not apply, since the entire switchgear needs to be evaluated.
10 2 6 Mechanical Impact	Does not apply, since the entire switchgear needs to be evaluated.
10 2 7 Inscriptions	Meets the product standard’s requirements.
10 3 Degree Of Protection Of Assemblies	Does not apply, since the entire switchgear needs to be evaluated.
10 4 Clearances And Creepage Distances	Meets the product standard’s requirements.
10 5 Protection Against Electric Shock	Does not apply, since the entire switchgear needs to be evaluated.
10 6 Incorporation Of Switching Devices And Components	Does not apply, since the entire switchgear needs to be evaluated.
10 7 Internal Electrical Circuits And Connections	Is the panel builder’s responsibility.
10 8 Connections For External Conductors	Is the panel builder’s responsibility.
10 9 2 Power Frequency Electric Strength	Is the panel builder’s responsibility.
10 9 3 Impulse Withstand Voltage	Is the panel builder’s responsibility.
10 9 4 Testing Of Enclosures Made Of Insulating Material	Is the panel builder’s responsibility.
Electric Connection Type	Screw connection
Frame	NZM⅔
Number Of Contacts Change Over Contacts	0.0000
Number Of Contacts Normally Closed Contacts	0.0000
Number Of Contacts Normally Open Contacts	0.0000
Rated Control Supply Voltage Us At Ac 50 Hz Max	525 VLT
Rated Control Supply Voltage Us At Ac 50 Hz Max Uom	VLT
Rated Control Supply Voltage Us At Ac 50 Hz Min	480 VLT
Rated Control Supply Voltage Us At Ac 50 Hz Min Uom	VLT
Rated Control Supply Voltage Us At Ac 60 Hz Max	525 VLT
Rated Control Supply Voltage Us At Ac 60 Hz Max Uom	VLT
Rated Control Supply Voltage Us At Ac 60 Hz Min	480 VLT
Rated Control Supply Voltage Us At Ac 60 Hz Min Uom	VLT
Rated Control Supply Voltage Us At Dc Max	525 VLT
Rated Control Supply Voltage Us At Dc Max Uom	VLT
Rated Control Supply Voltage Us At Dc Min	24 VLT
Rated Control Supply Voltage Us At Dc Min Uom	VLT
Special Features	Switches are tripped by a voltage pulse or by the application of uninterrupted voltage. If the shunt trip is live, contact with the circuit breaker’s primary contacts is prevented when switched on. Shunt releases cannot be installed simultaneously with NZM…-XHIV… early-make auxiliary contact or NZM…-XU… undervoltage release.
Suitable For	Off-load switch
Type	Accessory Shunt release
Undelayed Short Circuit Release Max	0 AMP
Undelayed Short Circuit Release Max Uom	AMP
Undelayed Short Circuit Release Min	0 AMP
Undelayed Short Circuit Release Min Uom	AMP
Used With	NZM3(-4), N(S)3(-4) Shunt releases, all sizes NZM2(-4), N(S)2(-4)
Voltage Type	AC/DC
