Eaton 1357A-6507
SKU: CS5018986MPN: 1357A-6507UPC/EAN: 782113824031
Eaton 55 series photoelectric sensor
Contact us for pricing and availability
Product Details
Eaton 55 series Photoelectric sensor Right Angle, Sensor distance: 72 In., 50 mA max DC, NPN and PNP Open Collector, 50 mA at 30 Vdc, 4 Pin Mini Connector, 10-30 Vdc input, Auto reset short circuit, Diffuse Reflective
Attributes
| Connection | 4-pin mini connector |
| Contact Configuration | NPN and PNP open collector |
| Contact Rating | 50 mA at 30 Vdc |
| Enclosure Material | Lens: nylon Body: noryl |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 6, NEMA 12, NEMA 13 |
| Input Voltage | 10-30 Vdc |
| Led Indicator | Output status: red |
| Maximum Dc Current | 50 mA |
| Operating Mode | Diffuse reflective |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -40 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Auto reset short circuit |
| Sensor Type | Diffuse reflective |
| Switch Type | Photoelectric |
Specifications
| SKU | CS5018986 |
|---|---|
| MPN | 1357A-6507 |
| UPC/EAN | 782113824031 |
