Eaton 13102A6517

Name: Eaton 13102A6517
Brand: Eaton
SKU: CS5018820
Price: 429.78 USD
Availability: OutOfStock

SKU: CS5018820MPN: 13102A6517UPC/EAN: 782113928173

Eaton Comet 18mm tubular photoelectric sensor

Product Details

Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 1.6 in, 100 mA PNP, 250 mA NPN max DC, NPN/PNP Open coll, 100 mA PNP, 250 mA NPN at 10-30 Vdc, 6.6 Ft.(2m) Cable, 10-30 Vdc input, Focused Spot Diffuse, 6.6 Ft.(2m)

Attributes

Cable Type	Polyvinyl Chloride (PVC)
Connection	6.6 ft (2 m) cable
Contact Configuration	NPN and PNP open collector
Contact Rating	100 mA PNP, 250 mA NPN at 10-30 Vdc
Enclosure Material	Body: structural polyurethane foam Cable jacket: PVC Lens: polycarbonate
Environmental Rating	NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K
Input Voltage	10-30 Vdc
Led Indicator	Output status: red
Maximum Dc Current	100 mA PNP, 250 mA NPN
Operating Mode	Focused spot diffuse
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-40 FAH
Operating Temperature Min Uom	FAH
Protection	Auto reset short circuit
Sensor Type	Focused diffuse
Switch Type	Photoelectric
