Eaton 12102A6517
SKU: CS5018476MPN: 12102A6517UPC/EAN: 782113887036
Eaton Comet 18mm tubular photoelectric sensor
Contact us for pricing and availability
Product Details
Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 80 Ft., 100 mA PNP, 250 mA NPN max DC, NPN/PNP Open Collector, 100 mA PNP, 250 mA NPN at 10-30 Vdc, 6.6 Ft.(2m) Cable, 10-30 Vdc input, Thru-beam, 6.6 Ft.(2m)
Attributes
| Cable Type | Polyvinyl Chloride (PVC) |
| Connection | 6.6 ft (2 m) cable |
| Contact Configuration | NPN and PNP open collector |
| Contact Rating | 100 mA PNP, 250 mA NPN at 10-30 Vdc |
| Enclosure Material | Lens: polycarbonate Body: structural polyurethane foam Cable jacket: PVC |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K |
| Input Voltage | 10-30 Vdc |
| Led Indicator | Output status: red |
| Maximum Dc Current | 100 mA PNP, 250 mA NPN |
| Operating Mode | Thru-beam |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -40 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Auto reset short circuit |
| Sensor Type | Through beam |
| Switch Type | Photoelectric |
Specifications
| SKU | CS5018476 |
|---|---|
| MPN | 12102A6517 |
| UPC/EAN | 782113887036 |
