Eaton 13106A6517
SKU: CS5018855MPN: 13106A6517UPC/EAN: 782113823461
Eaton Comet 18mm tubular photoelectric sensor
Contact us for pricing and availability
Product Details
Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 8 In., 100 mA PNP, 250 mA NPN max DC, NPN/PNP Open Collector, 100 mA PNP, 250 mA NPN at 10-30 Vdc Cable, 10-30 Vdc input, Diffuse Reflective
Attributes
| Cable Type | Polyvinyl Chloride (PVC) |
| Connection | 6.6 ft (2 m) cable |
| Contact Configuration | NPN and PNP open collector |
| Contact Rating | 100 mA PNP, 250 mA NPN at 10-30 Vdc |
| Enclosure Material | Body: structural polyurethane foam Cable jacket: PVC Lens: polycarbonate |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K |
| Input Voltage | 10-30 Vdc |
| Led Indicator | Output status: red |
| Maximum Dc Current | 100 mA PNP, 250 mA NPN |
| Operating Mode | Diffuse reflective |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -40 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Auto reset short circuit |
| Sensor Type | Diffuse reflective |
| Switch Type | Photoelectric |
Specifications
| SKU | CS5018855 |
|---|---|
| MPN | 13106A6517 |
| UPC/EAN | 782113823461 |
