Eaton 13100A6517
SKU: CS3588848MPN: 13100A6517UPC/EAN: 782113823256
Eaton Comet 18mm tubular photoelectric sensor
Contact us for pricing and availability
Product Details
Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 24 In., 100 mA PNP, 250 mA NPN max DC, NPN/PNP Open Collector, 100 mA PNP, 250 mA NPN at 10-30 Vdc Cable, 10-30 Vdc input, Diffuse Reflective
Attributes
| Cable Type | Polyvinyl Chloride (PVC) |
| Connection | 6.6 ft (2 m) cable |
| Contact Configuration | NPN and PNP open collector |
| Contact Rating | 100 mA PNP, 250 mA NPN at 10-30 Vdc |
| Enclosure Material | Cable jacket: PVC Lens: polycarbonate Body: structural polyurethane foam |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K |
| Input Voltage | 10-30 Vdc |
| Led Indicator | Output status: red |
| Maximum Dc Current | 100 mA PNP, 250 mA NPN |
| Operating Mode | Diffuse reflective |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -40 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Auto reset short circuit |
| Sensor Type | Diffuse reflective |
| Switch Type | Photoelectric |
Specifications
| SKU | CS3588848 |
|---|---|
| MPN | 13100A6517 |
| UPC/EAN | 782113823256 |
