Eaton XTMC9A01WD

Name: Eaton XTMC9A01WD
Brand: Eaton
SKU: CS5010073
Price: 63.89 USD
Availability: OutOfStock

SKU: CS5010073MPN: XTMC9A01WDAlternate Part #: MSAA010496UPC/EAN: 04015080104964

Eaton XT IEC mini contactor

Eaton XTMC6A01AD, XTMC6A01BD, XTMC6A01F, XTMC6A01G, XTMC6A01H, XTMC6A01L, XTMC6A01P, XTMC6A01R, XTMC6A01RD, XTMC6A01W, XTMC6A01WD, XTMC6A01Y, XTMC9A01BD, XTMC9A01D, XTMC9A01F

Product Details

Eaton XT IEC mini contactor, 8.80A, 48 Vdc, 1NC, 20A, 45 mm mini, 0.5, 1, 1.5/ 2, 3, 5, 5 hp (⅓PH @115, 200, 230/200, 230, 460, 575 V), Three-pole, Non-reversing, , Screw terminals, Full voltage non-reversing mini contactor

Attributes

Amperage Rating	8.80A
Coil Voltage	48 Vdc
Contact Configuration	1 NC
Continuous Ampere Rating	20 A
Hp Rating Max	0.5, 1, 1.5/ 2, 3, 5, 5 hp (⅓PH @115,200,230/200,230,460,575 V)
Number Of Poles	Three-pole
Operation	Non-reversing
Series	XT IEC
Terminals	Screw terminals
Type	Full voltage non-reversing mini contactor
