Eaton FRBM6-C16/1N/003-A

Name: Eaton FRBM6-C16/1N/003-A
Brand: Eaton
SKU: CS4877519
Price: 827.67 USD
Availability: OutOfStock

SKU: CS4877519MPN: FRBM6-C16/1N/003-AAlternate Part #: 177925UPC/EAN: 04015081724987

Eaton Moeller series xEffect - FRBm6/M RCBO - residual-current circuit breaker with overcurrent protection

Product Details

Eaton RCD/MCB combination switch, 16 A, 30 mA, miniature circuit-breaker type C trip characteristic, 1pole+N, residual current circuit-breaker trip characteristic: A. FRBM6-C16/1N/003-A

Attributes

10 10 Temperature Rise	The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
10 11 Short Circuit Rating	Is the panel builder’s responsibility. The specifications for the switchgear must be observed.
10 12 Electromagnetic Compatibility	Is the panel builder’s responsibility. The specifications for the switchgear must be observed.
10 13 Mechanical Function	The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
10 2 2 Corrosion Resistance	Meets the product standard’s requirements.
10 2 3 1 Verification Of Thermal Stability Of Enclosures	Meets the product standard’s requirements.
10 2 3 2 Verification Of Resistance Of Insulating Materials To Normal Heat	Meets the product standard’s requirements.
10 2 3 3 Resist Of Insul Mat To Abnormal Heat Fire By Internal Elect Effects	Meets the product standard’s requirements.
10 2 4 Resistance To Ultra Violet Uv Radiation	Meets the product standard’s requirements.
10 2 5 Lifting	Does not apply, since the entire switchgear needs to be evaluated.
10 2 6 Mechanical Impact	Does not apply, since the entire switchgear needs to be evaluated.
10 2 7 Inscriptions	Meets the product standard’s requirements.
10 3 Degree Of Protection Of Assemblies	Does not apply, since the entire switchgear needs to be evaluated.
10 4 Clearances And Creepage Distances	Meets the product standard’s requirements.
10 5 Protection Against Electric Shock	Does not apply, since the entire switchgear needs to be evaluated.
10 6 Incorporation Of Switching Devices And Components	Does not apply, since the entire switchgear needs to be evaluated.
10 7 Internal Electrical Circuits And Connections	Is the panel builder’s responsibility.
10 8 Connections For External Conductors	Is the panel builder’s responsibility.
10 9 2 Power Frequency Electric Strength	Is the panel builder’s responsibility.
10 9 3 Impulse Withstand Voltage	Is the panel builder’s responsibility.
10 9 4 Testing Of Enclosures Made Of Insulating Material	Is the panel builder’s responsibility.
Application	Switchgear for industrial and advanced commercial applications
Basic Function	Combined RCD/MCB devices
Current Limiting Class	3.0000
Degree Of Protection	IP20
Equipment Heat Dissipation Current Dependent	3.6 W
Fault Current Rating	0.03 AMP
Fault Current Rating Uom	AMP
Features	Concurrently switching N-neutral
Frequency Rating	50 Hz
Leakage Current Type	A
Number Of Poles	Single-pole + N
Number Of Poles Protected	1.0000
Number Of Poles Total	2.0000
Operating Ambient Temperature Max	40 CEL
Operating Ambient Temperature Max Uom	CEL
Operating Ambient Temperature Min	-25 CEL
Operating Ambient Temperature Min Uom	CEL
Overvoltage Category	III
Pollution Degree	2.0000
Rated Current	16 AMP
Rated Current Uom	AMP
Rated Operational Current For Specified Heat Dissipation In	16 AMP
Rated Operational Current For Specified Heat Dissipation In Uom	AMP
Rated Short Circuit Breaking Capacity En 60947 2	0 B22
Rated Short Circuit Breaking Capacity En 60947 2 Uom	B22
Release Characteristic	C
Surge Current Capacity	0.25 B22
Surge Current Capacity Uom	B22
Type	RCBO
Voltage Rating	240 V - 240 V
Voltage Rating Uom	B22
Voltage Type	AC
