Veris PW2LX05BP

Differential Air Pressure Trans: For the monitoring of air ducts, filters and fans, SPD310-100/300/500/1000Pa

12 to 24 VDC Input 4 to 20 mA Output Wet Media Differential Pressure Transducer with LCD Display, 0 to 250 paig, Bypass

• Application Zone : Plant Room
• Application : Pump and Compressor Differential Pressure, Chiller Differential Pressure Monitoring
• Brand : Veris
• Burst Pressure : 1,250 psi (85 bar)
• Calibration Certificate : No
• Dimension Depth : 2.6 In (67 mm)
• Dimension Height : 12 In (305 mm)
• Dimension Width : 8.7 In (221 mm)
• Display Size : 0.7 In x 1.4 In (17 mm x 36 mm)
• Display Type : LCD
• Electrical Wiring : 2-wires (loop-powered)
• Enclosure Material : Powder Coated Aluminium
• Fitting Material : Stainless Steel
• Fitting Size : 1/ 8 In NPT
• Fitting Type : Female
• IP Protection : IP65 (NEMA 4)
• Measurement Type : Differential Pressure
• Medium : Water
• Model : PW2LX05BP
• Mounting : Panel
• Operating Current : 29 mA
• Operating Humidity : 0 - 90% RH, non-condensing
• Operating Temperature : -4 - 130 °F (-10 - 55 °C)
• Output Specifications : 4 - 20 mA
• Outputs : Analog output
• Pressure Measurement Accuracy : Range A, B and C: ±1% of F.S. Range D: ±2% of F.S.
• Pressure Measurement Range : 0 - 25 psi (0 - 1.7 bar), 0 - 50 psi (0 - 3.5 bar), 0 - 100 psi (0 - 7 bar), 0 - 250 psi (0 - 17 bar)
• Product Certification : CE
• Product Type : Sensor
• Range : PW2
• Standards EMC : EN 61000-6-1
• Supply Voltage DC Range : 12 - 24 VDC
