Square D XMLB160D2S11

Name: Square D XMLB160D2S11
Brand: Square D
SKU: CS4814063
Availability: OutOfStock

SKU: CS4814063MPN: XMLB160D2S11

pressure switch XMLB 160 bar - adjustable scale 2 thresholds - 1 C/O

Product Details

Electromechanical pressure sensor, Pressure sensors XM, switch XMLB 160 bar, adjustable scale 2 thresholds, 1 C/O

Adjustable Range Of Switching Point On Falling Pressure	0.7-139.2 bar
Adjustable Range Of Switching Point On Rising Pressure	10-160 bar
Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Auxiliary Contacts Operation	snap action
Awg Gauge	AWG 20…AWG 14
Contacts Material	silver contacts
Destruction Pressure	720 bar
Device Short Name	XMLB
Electrical Circuit Type	control circuit
Enclosure Material	zinc alloy
Local Display	with
Materials In Contact With Fluid	steel# #PTFE# #brass# #FPM, FKM
Maximum Permissible Accidental Pressure	360 bar
Maximum Permissible Pressure Per Cycle	200 bar
Mechanical Durability	6000000 cycles
Operating Position	any position
Possible Differential Maximum At High Setting	100 bar
Pressure Actuator	piston
Pressure Sensor Size	160 bar
Pressure Sensor Size 1	160 bar
Pressure Sensor Type	electromechanical pressure sensor
Pressure Switch Type Of Operation	regulation between 2 thresholds
Product Certifications	BV# #CSA# #UL# #CCC# #LROS (Lloyds register of shipping)# #EAC
Product Or Component Type	electromechanical pressure sensor
Product Specific Application	-
Range Of Product	Telemecanique Pressure sensors XM
Scale Type	adjustable differential
Setting	external
Standards	UL 508# #EN/IEC 60947-5-1# #CSA C22.2 No 14# #CE
Terminal Block Type	4 terminals
