Square D XMLA160D2S13

Name: Square D XMLA160D2S13
Brand: Square D
SKU: CS4814059
Availability: OutOfStock

SKU: CS4814059MPN: XMLA160D2S13

pressure switch XMLA 160 bar - fixed scale 1 threshold - 1 C/O

Product Details

OsiSense XMLA Pressure Switch

Pressure Sensor Size: 160 Bar* Scale Type: Fixed Differential* Pressure Switch Type of Operation: Detection of 1 Single Threshold* Contacts Type and Composition: 1 C/O* Degree of Protection: IP66

Adjustable Range Of Switching Point On Falling Pressure	4.5-142 bar
Adjustable Range Of Switching Point On Rising Pressure	10-160 bar
Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Auxiliary Contacts Operation	snap action
Awg Gauge	AWG 20…AWG 14
Contacts Material	silver contacts
Destruction Pressure	720 bar
Device Short Name	XMLA
Electrical Circuit Type	control circuit
Enclosure Material	zinc alloy
Local Display	with
Materials In Contact With Fluid	brass# #PTFE# #steel# #FPM, FKM
Maximum Permissible Accidental Pressure	360 bar
Maximum Permissible Pressure Per Cycle	200 bar
Mechanical Durability	6000000 cycles
Operating Position	any position
Pressure Actuator	piston
Pressure Sensor Size	160 bar
Pressure Sensor Size 1	160 bar
Pressure Sensor Type	electromechanical pressure sensor
Pressure Switch Type Of Operation	detection of 1 single threshold
Product Certifications	LROS (Lloyds register of shipping)# #EAC# #UL# #CCC# #CSA# #BV
Product Or Component Type	electromechanical pressure sensor
Product Specific Application	-
Range Of Product	Telemecanique Pressure sensors XM
Scale Type	fixed differential
Setting	external
Standards	CE# #CSA C22.2 No 14# #UL 508# #EN/IEC 60947-5-1
Terminal Block Type	4 terminals
