Square D PCSP060D5IP00

Name: Square D PCSP060D5IP00
Brand: Square D
SKU: CS4812463
Availability: OutOfStock

SKU: CS4812463MPN: PCSP060D5IP00

Active harmonic filter - 60 A 380..480 V AC - IP00 enclosure

Product Details

Active harmonic filter - 60 A 380..480 V AC - IP00 enclosure

Range of product: AccuSine
Product name: AccuSine PCS+
Product or component type: Active harmonic filter
Network type: 3P
Network configuration: 3 or 4 wires
Network rated voltage: 380…480 V AC
Network frequency: 50/60 Hz +/- 3 Hz auto sensing
Maximum permissible voltage: 1.1 x Un
Neutral correction: Not provided
RMS output current rating: 60 A
Reactive power rating: 50 kvar 480 V AC 50/60 Hz
Operating modes: Harmonic cancellation, Power factor correction, Mains current balancing
Installation location: Indoor
Enclosure mounting: Wall mounted
Protection type: Without protection
Heat dissipation: Rear plenum with forced ventilation for high heat flow
Accessibility for operation: Front
location of connection: Bottom

Accessibility For Operation	front
Ambient Air Temperature For Storage	-20-60 °C
Enclosure Mounting	wall mounted
Function Available	rear plenum with forced ventilation for high heat flow
Impregnation Material	conformal coated
Ip Degree Of Protection	IP00
Location Of Connection	bottom
Maximum Permissible Voltage	1.1 x Un
Mounting Location	indoor
Neutral Protection Setting	not provided
Nominal Output Current	60 A
Operating Mode	harmonic cancellation# #mains current balancing# #power factor correction
Poles Description	3P
Product Certifications	DNV-GL# #ABS# #RCM# #CE# #cULus
Product Name	AccuSine PCS+
Product Or Component Type	active harmonic filter
Protection Type	without protection
Range Of Product	AccuSine
Standards	UL 508# #CSA C22.2 No 60947-1-07# #UL 60947-1# #EN 61000-6-4# #EN 60439-1# #CSA C22.2 No 14
Wiring Mode	3 or 4 wires
