Square D PCSP300D5N1

Name: Square D PCSP300D5N1
Brand: Square D
SKU: CS4812469
Availability: OutOfStock

SKU: CS4812469MPN: PCSP300D5N1

Active harmonic filter 300 amp 380-480 VAC N1 Enclosure

Product Details

Active harmonic filter 300 amp 380-480 VAC N1 Enclosure

Accessibility For Operation	front
Ambient Air Temperature For Storage	-20-60 °C
Breaking Capacity	200 kA
Control Type	door-interlocked with rotary handle
Degree Of Protection	UL type 1
Enclosure Mounting	floor-standing
Function Available	rear plenum with forced ventilation for high heat flow
Impregnation Material	conformal coated
Location Of Connection	top or bottom
Maximum Permissible Voltage	1.1 x Un
Mounting Location	indoor
Neutral Protection Setting	not provided
Nominal Output Current	300 A
Operating Mode	power factor correction# #harmonic cancellation# #mains current balancing
Poles Description	3P
Product Certifications	ABS# #cULus# #CE# #RCM
Product Name	AccuSine PCS+
Product Or Component Type	active harmonic filter
Protection Type	circuit breaker protection
Range Of Product	AccuSine
Standards	UL 60947-1# #UL 508# #CSA C22.2 No 60947-1-07# #EN 61000-6-4# #EN 60439-1# #CSA C22.2 No 14
Wiring Mode	3 or 4 wires
