Square D PCSP235D6N2

Name: Square D PCSP235D6N2
Brand: Square D
SKU: CS4812468
Availability: OutOfStock

SKU: CS4812468MPN: PCSP235D6N2

Active harmonic filter 235 amp 500-600 VAC N2 Enclosure

Product Details

Active harmonic filter 235 amp 500-600 VAC N2 Enclosure

Accessibility For Operation	front
Ambient Air Temperature For Storage	-20-60 °C
Breaking Capacity	100 kA
Control Type	door-interlocked with rotary handle
Degree Of Protection	UL type 2
Enclosure Mounting	floor-standing
Function Available	rear plenum with forced ventilation for high heat flow
Impregnation Material	conformal coated
Location Of Connection	top or bottom
Maximum Permissible Voltage	1.1 x Un
Mounting Location	indoor
Neutral Protection Setting	not provided
Nominal Output Current	235 A
Operating Mode	harmonic cancellation# #power factor correction# #mains current balancing
Poles Description	3P
Product Certifications	CE# #RCM# #cULus# #ABS
Product Name	AccuSine PCS+
Product Or Component Type	active harmonic filter
Protection Type	circuit breaker protection
Range Of Product	AccuSine
Standards	CSA C22.2 No 14# #UL 60947-1# #EN 61000-6-4# #CSA C22.2 No 60947-1-07# #EN 60439-1# #UL 508
Wiring Mode	3 or 4 wires
