Square D 8502SEA2V03
SKU: CS4809703MPN: 8502SEA2V03
NEMA Contactor, Type S, nonreversing, Size 3, 90A, 50 HP at 575 VAC, 3 phase, up to 100 kA, 3 pole, 240VAC coil, NEMA 12
Contact us for pricing and availability
Product Details
Magnetic contactors class 8502
- Line Rated Current 90 A
- Network type : AC
- Number of Poles : 3P
- Control circuit voltage : 240 V AC 60 Hz / 220 V AC 50 Hz
- Contactor application : Non-reversing
- Rated operational voltage : 600 V AC
- NEMA degree of protection : NEMA 12 painted sheet steel
Attributes
| In Rated Current | 90 A |
| In Rated Current 1 | 90 A |
| Auxiliary Contact Composition | without |
| Contactor Application | non-reversing |
| Control Circuit | common control circuit |
| Electrical Connection | screw clamp terminals |
| Nema Size | 3 |
| Network Number Of Phases | 3 phases |
| Poles Description | 3P |
| Product Certifications | UL listed file E78351 CCN NLDX# #CSA |
| Product Or Component Type | contactor |
| Provided Equipment | fuse not supplied |
| Range Of Product | 8502S |
Specifications
| SKU | CS4809703 |
|---|---|
| MPN | 8502SEA2V03 |
