Square D 8502SEO1V02S

Name: Square D 8502SEO1V02S
Brand: Square D
SKU: CS4809704
Availability: OutOfStock

SKU: CS4809704MPN: 8502SEO1V02SUPC/EAN: 785901790730

NEMA Contactor, Type S, nonreversing, Size 3, 90A, 1 phase, up to 100 kA, 2 pole, 120 VAC coil, open

Product Details

Class 8502 Type S Full Voltage Magnetic Contactor:

Non-Reversing* NEMA Size: 3* NEMA Degree of Protection: Not Rated* Line Rated Current: 90A* Rated Power in Horsepower: Not Rated* Phase: 1-Phase* Number of Poles: 2-Pole* Control Circuit: Separate Control Circuit* Control Circuit Voltage: 110 VAC 50HZ, 120 VAC 60Hz* Mounting: Surface* System Voltage: 600VAC* Electrical Connection: Screw Clamp Terminals

In Rated Current	90 A
In Rated Current 1	90 A
Auxiliary Contact Composition	without
Contactor Application	non-reversing
Control Circuit	separate control circuit
Electrical Connection	screw clamp terminals
Nema Size	3
Network Number Of Phases	1 phase
Poles Description	2P
Product Certifications	UL listed file E78351 CCN NLDX# #CSA
Product Or Component Type	contactor
Provided Equipment	fuse not supplied
Range Of Product	8502S
