Square D 8502SDA2V02S

Name: Square D 8502SDA2V02S
Brand: Square D
SKU: CS4809699
Availability: OutOfStock

SKU: CS4809699MPN: 8502SDA2V02SUPC/EAN: 785901458456

NEMA Contactor, Type S, nonreversing, Size 2, 45A, 25 HP at 575 VAC, 3 phase, up to 100 kA, 3 pole, 120VAC coil, NEMA 12

Product Details

Class 8502 Type S Full Voltage Magnetic Contactor:

Non-Reversing* NEMA Size: 2* NEMA Degree of Protection: NEMA 12 Painted Sheet Steel* Line Rated Current: 45A* Rated Power in Horsepower: 25 HP 575 VAC, 15 HP 230 VAC, 10 HP 200VAC, 25 HP 460 VAC* Phase: 3-Phase* Number of Poles: 3-Pole* Control Circuit: Separate Control Circuit* Control Circuit Voltage: 110 VAC 50HZ, 120 VAC 60Hz* Mounting: Surface* System Voltage: 600VAC* Electrical Connection: Screw Clamp Terminals

In Rated Current	45 A
In Rated Current 1	45 A
Auxiliary Contact Composition	without
Contactor Application	non-reversing
Control Circuit	separate control circuit
Electrical Connection	screw clamp terminals
Nema Size	2
Network Number Of Phases	3 phases
Poles Description	3P
Product Certifications	UL listed file E78351 CCN NLDX# #CSA
Product Or Component Type	contactor
Provided Equipment	fuse not supplied
Range Of Product	8502S
