Square D 8501CO6V14
SKU: CS4809653MPN: 8501CO6V14UPC/EAN: 785901052029
Power Relay, Type C, 2.0 HP, 30A resistive at 300 VAC, SPST, 1 normally open contact, 24 VAC coil
$35.80
UnitAvailable on backorder
Product Details
RELAY 600VAC 10AMP TYPE C +OPTIONS
Attributes
| In Rated Current | 30 A |
| In Rated Current 1 | 30 A |
| Ambient Air Temperature For Operation | -22-122 °F |
| Ambient Air Temperature For Operation 1 | -22-122 °F |
| Catalog Class | 8501.0000 |
| Connections Terminals | screw clamp terminal |
| Contacts Type And Composition | 1 NO |
| Device Application | suited for controlling small single phase motors and other light loads |
| Device Short Name | type C |
| Hold In Power Consumption In Va | 10-10 VA |
| Mounting Support | panel mounting |
| Network Number Of Phases | 1 phase |
| Product Certifications | UL listed file E78351 CCN NLDX# #CSA# #CE |
| Product Or Component Type | power relay |
| Range Of Product | Power Relay 8501C |
| Rated Power In Hp | 2 hp |
| Switch Function | SPST |
| Tightening Torque | 11-15 lbf.in |
| Tightening Torque 1 | 11-15 lbf.in |
Specifications
| SKU | CS4809653 |
|---|---|
| MPN | 8501CO6V14 |
| UPC/EAN | 785901052029 |
