Square D 8501CO15V04

Name: Square D 8501CO15V04
Brand: Square D
SKU: CS4809649
Availability: OutOfStock

SKU: CS4809649MPN: 8501CO15V04UPC/EAN: 785901052265

Power Relay, Type C, 2 hp, 30A resistive at 300 VAC, SPDT, 1 normally open and 1 normally closed contact, 277 VAC coil

Product Details

Power Relay Type C

Line Rated Current: 30A* Control Circuit Voltage: 277V AC 60 Hz* Rated Power in HP: 1.5 HP* Maximum Switching Voltage: 600V AC* Switch Function: SPDT* Contacts type and Composition: 1NO + 1NC* Mounting Support: Panel Mount* Number of Phases: 1-Phase* Connections-Terminals: Screw Clamp Terminals

In Rated Current	30 A
In Rated Current 1	30 A
Ambient Air Temperature For Operation	-22-122 °F
Ambient Air Temperature For Operation 1	-22-122 °F
Catalog Class	8501.0000
Connections Terminals	screw clamp terminal
Contacts Type And Composition	1 NO/1 NC
Device Application	suited for controlling small single phase motors and other light loads
Device Short Name	type C
Hold In Power Consumption In Va	10-10 VA
Mounting Support	panel mounting
Network Number Of Phases	1 phase
Product Certifications	UL listed file E78351 CCN NLDX# #CSA# #CE
Product Or Component Type	power relay
Range Of Product	Power Relay 8501C
Rated Power In Hp	2.0 hp
Switch Function	SPDT
Tightening Torque	11-15 lbf.in
Tightening Torque 1	11-15 lbf.in
