APC SUM1500RMXL2U

Name: APC SUM1500RMXL2U
Brand: APC
SKU: CS4805417
Availability: OutOfStock

SKU: CS4805417MPN: SUM1500RMXL2UUPC/EAN: 731304224549

APC Smart-UPS XL Modular 1500VA 120V Rackmount/Tower (Not for sale in CO, VT or WA)

Documents

APC SUM1500RMXL2U, SUM3000RMXL2U Manual

Product Details

APC Smart-UPS XL Modular 1500VA 120V Rackmount/Tower

APC Smart-UPS,1425 Watts /1440 VA,Input 120V /Output 120V, Interface Port DB-9 RS-232, RJ-45 10/100 Base-T, USB, Extended runtime model, Rack Height 2 U

Includes: CD with software, Installation guide, Rack Mounting brackets, Rack Mounting support rails, Smart UPS signalling RS-232 cable, USB cable, User Manual, Web/SNMP Management Card

Attributes

Sena Acoustic Level	55 dBA
Sena Additional Specification	network card pre-installed
Sena Alarm	alarm when on battery : distinctive low battery alarm : configurable delays
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-5-55 °C
Sena Battery Charger Power	199 W rated
Sena Battery Curve	C
Sena Battery Life	3-5 year(s)
Sena Battery Option	SUM48RMXLBP2U 1 1440 VAh SUM48RMXLBP2U 10 10080 VAh SUM48RMXLBP2U 2 2400 VAh SUM48RMXLBP2U 3 3360 VAh SUM48RMXLBP2U 4 4320 VAh SUM48RMXLBP2U 5 5280 VAh SUM48RMXLBP2U 6 6240 VAh SUM48RMXLBP2U 8 8160 VAh
Sena Battery Recharge Time	3 h
Sena Battery Type	VRLA
Sena Bypass Type	internal bypass (automatic and manual)
Sena Control Panel	LED status display with load and battery bar-graphs and on line : on battery : replace battery : overload and bypass indicators
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0228
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0300
Sena Curve Square Loss	0.0169
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the US DOE Test Procedure for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF = 1.
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Emergency Power Off	optional
Sena Equipment Protection Policy	lifetime : $150000
Sena Extended Runtime	1.0000
Sena Graph Display	1.0000
Sena Heat Dissipation	300 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Input Voltage Limits	75…154 V adjustable 82…147 V
Sena Maximum Configurable Power In Va	1440 VA
Sena Maximum Configurable Power In W	1425 W
Sena Maximum Output Current	24 A
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	8 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Rack Unit	2U
Sena Number Of Tare Power	90 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA 5-15P
Sena Preinstalled Device	network management card 2 with environmental monitoring
Sena Product Certifications	BSMI# #CSA# #NOM# #VCCI class A
Sena Provided Equipment	CD with software installation guide rack mounting brackets rack mounting support rails Smart UPS signalling RS-232 cable USB cable user manual web/SNMP management card
Sena Provided Equipment 1	CD with software installation guide rack mounting brackets rack mounting support rails Smart UPS signalling RS-232 cable USB cable user manual web/SNMP management card
Sena Provided Equipment 2	CD with software installation guide rack mounting brackets rack mounting support rails Smart UPS signalling RS-232 cable USB cable user manual web/SNMP management card
Sena Rated Power In Va	1440 VA
Sena Rated Power In W	1425 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Size Ups Version	server
Sena Standards	FCC part 15 class A# #UL 1778
Sena Storage Altitude	0-30000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	540 J
Sena Ups Design Life	6 year(s)
Sena Ups Size	S
Sena Ups Type	line interactive
Sena Usb Compatible	No
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
