APC AP9627

Name: APC AP9627
Brand: APC
SKU: CS4805173
Availability: OutOfStock

SKU: CS4805173MPN: AP9627UPC/EAN: 731304249146

APC Step-Down Transformer RM 2U 208V IN 120V OUT w/L5-20 Receptacles

Documents

APC AP9626, AP9627 Manual

Product Details

APC Step-Down Transformer RM 2U 208V IN 120V OUT w/L5-20 Receptacles

APC Step-Down Transformer, Input: 208V, Input Connections: NEMA L6-30P, Cord Length:2 feet ( 0.61 meters ), Output: 120V, Output Connections: NEMA L5-20R

Includes: Rack Mounting brackets, User Manual

Attributes

Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-25-65 °C
Sena Colour	black
Sena Colour 1	black
Sena Curve Equation	efficiency
Sena Curve Load Maximum	1.0000
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Efficiency	0.89999997615814
Sena Efficiency 1	0.89999997615814
Sena Input Current Limits	26 A
Sena Input Voltage	208 V
Sena Input Voltage 1	208 V
Sena Load Capacity	5000 VA
Sena Max Current Draw	20 A
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Preference	no preference
Sena Network Frequency	60 Hz ± 3 Hz
Sena Number Of Cables	1.0000
Sena Number Of Power Socket Outlets	4 NEMA L5-20R
Sena Number Of Power Socket Outlets 1	4 NEMA L5-20R
Sena Number Of Rack Unit	2U
Sena Operating Altitude	0…10000 ft
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Plug Standard	NEMA L6-30P
Sena Product Certifications	CSA# #UL listed
Sena Protection Type	circuit breaker
Sena Relative Humidity	0-95 %
Sena Standards	UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Ups Size	S
