APC SBP3000RM2U

Name: APC SBP3000RM2U
Brand: APC
SKU: CS3104708
Availability: OutOfStock

SKU: CS3104708MPN: SBP3000RM2UAlternate Part #: APC-SBP3000RM2UUPC/EAN: 731304212577

APC Service Bypass Panel- 100-120V; 30A; BBM; L5-30P input; (2) 5-20R (6) 5-15R output

Product Details

SVC BYPASS PNL 100-120V 30A

Sena Ambient Air Temperature For Operation	-20-50 °C
Sena Ambient Air Temperature For Storage	-25-65 °C
Sena Colour	black
Sena Colour 1	black
Sena Curve Equation	efficiency
Sena Curve Load Maximum	1.0000
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Efficiency	0.99000000953674
Sena Efficiency 1	0.99000000953674
Sena Input Current Limits	24 A
Sena Input Voltage	100 V 120 V
Sena Input Voltage 1	100 V 120 V
Sena Load Capacity	3000 VA
Sena Max Current Draw	30 A
Sena Max Line Current	24 A
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Preference	lower
Sena Network Frequency	50/60 Hz
Sena Number Of Power Socket Outlets	2 NEMA 5-20R 6 NEMA 5-15R
Sena Number Of Power Socket Outlets 1	2 NEMA 5-20R 6 NEMA 5-15R
Sena Number Of Rack Unit	2U
Sena Operating Altitude	0…15000 ft
Sena Output Voltage	100 V 120 V
Sena Output Voltage 1	100 V 120 V
Sena Plug Standard	NEMA L5-30P
Sena Power Factor	0-1
Sena Product Certifications	CSA# #GOST
Sena Protection Type	circuit breaker
Sena Relative Humidity	0-95 %
Sena Standards	EN 60950# #IEC 60950# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Ups Size	L
