APC APTF10KT01

Name: APC APTF10KT01
Brand: APC
SKU: CS4805194
Availability: OutOfStock

SKU: CS4805194MPN: APTF10KT01UPC/EAN: 731304242215

APC 208V/120V 10KVA Step down Transformer

Product Details

APC 208V/120V 10KVA Step down Transformer

The Step-Down Transformer converts high voltage (208 or 200 VAC) output into low voltage (120 or 100 VAC) output for powering low voltage AC equipment.

Includes: Documentation CD, Hardwire Panel, Installation Guide, Rack Mounting Brackets, User Manual

Attributes

Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-25-65 °C
Sena Colour	black
Sena Colour 1	black
Sena Curve Equation	efficiency
Sena Curve Load Maximum	1.0000
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Efficiency	0.94999998807907
Sena Efficiency 1	0.94999998807907
Sena Input Current Limits	60 A
Sena Input Voltage	208 V
Sena Input Voltage 1	208 V
Sena Load Capacity	10000 VA
Sena Max Current Draw	60 A
Sena Max Line Current	60 A
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted with kit
Sena Mounting Preference	lower
Sena Network Frequency	45…65 Hz
Sena Number Of Input Connectors	1 hard wire 3-wire (2P + E)
Sena Number Of Power Socket Outlets	2 NEMA L14-30R 2 NEMA L5-20R
Sena Number Of Power Socket Outlets 1	2 NEMA L14-30R 2 NEMA L5-20R
Sena Number Of Rack Unit	4U
Sena Operating Altitude	0…10000 ft
Sena Output Connector Type	hard wire 3-wire (2P + E) 1 hard wire 4-wire (2P + N + E) 1
Sena Output Voltage	120 V 208 V 240 V
Sena Output Voltage 1	120 V 208 V 240 V
Sena Permissible Voltage	200-240 V
Sena Product Certifications	C-Tick# #CE# #CSA# #GOST# #UL listed# #VDE
Sena Protection Type	circuit breaker
Sena Relative Humidity	0-95 %
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Ups Size	S
