Dwyer DPMX-1

Name: Dwyer DPMX-1
Brand: Dwyer
SKU: CS4117432
Price: 694.59 USD
Availability: OutOfStock

SKU: CS4117432MPN: DPMX-1Alternate Part #: 124575-00

DPMX-1 W/ BLUE LED DISPLAY

$694.59

Unit

Available on backorder

Quantity

remove

add

Product Details

Extra large digital panel meter, blue LED segment display, with 90 to 250 VAC supply power.

Accuracy	±(1% F.S. + 1 count).
Commodity Code	R2VO
Display	3-½ digits, 2.3” height, 7 segment LED
Input	Set Voltage: ±200 mVDC, ±2 VDC, ±20 VDC; Adjustable Voltage: 200 mVDC, 5 VDC, 10 VDC; Adjustable Current: 0(4) to 20 mA DC.
Input Impedance	Set Voltage: >1 MÎ© (>10 MÎ© on 200 mV range); Adjustable Voltage: 392 kÎ©; Adjustable Current: 300Î© nominal.
Inputs	Set Voltage: ±200 mVDC, ±2 VDC, ±20 VDC; Adjustable Voltage: 200 mVDC, 5 VDC, 10 VDC; Adjustable Current: 0(4) to 20 mA DC.
Mounting	180° gimbal mounting with 30° stops or bezel mount.
Operating Temperature	14 to 122°F ( -10 to 50°C).
Power Supply	90 to 250 VAC @ 12 VA or 10.5 to 30 VAC/DC @ 6 VA (depending on model).
Sampling Rate	3 readings per s.
Storage Range	-40 to 167°F (-40 to 75°C).
Warm Up	10 m.
