Square D RMCL55BD

Name: Square D RMCL55BD
Brand: Square D
SKU: CS3903458
Price: 181.83 USD
Availability: OutOfStock

SKU: CS3903458MPN: RMCL55BD

Voltage or current converter, Harmony Analog, Isolated 0...20mA

$181.83

Unit

Available on backorder

Quantity

remove

add

Product Details

Zelio Isoled Analog Converter

Analog Input Type: Current 0-20 mA, 4-20 mA, Voltage +/- 10V DC, 0-10V DC* Rated Supply Voltage: 24V DC +/- 20% non isolated* Local Signaling: LED Green (power ON)* Degree of Protection: IP20 terminal block, IP50 housing

Ui Rated Insulation Voltage	2 kV
Ambient Air Temperature For Storage	-40-85 °C
Clamping Connection Capacity	2 x 1.5 mm²# #1 x 2.5 mm²
Disturbance Radiated Conducted	CISPR 22 group 1 - class B# #CISPR 11
Marking	CE
Marking 1	CE
Product Certifications	UL# #GL# #CSA
Product Or Component Type	voltage/current converter
Protection Type	reverse polarity protection on output# #short-circuit protection on output# #overvoltage protection on output (± 30 V)
Range Of Product	Harmony Analog
Safety Reliability Data	B10d = 20000# #MTTFd = 21.6 years
Standards	IEC 60947-1# #IEC 60584-1
Tightening Torque	0.6-1.1 N.m
Tightening Torque 1	0.6-1.1 N.m
Tightening Torque 2	0.6-1.1 N.m
