Turck RM-89S10S-9B28B-B2M12
SKU: CS3854568MPN: RM-89S10S-9B28B-B2M12Alternate Part #: 1562098
1562098 - MULTITURN
Contact us for pricing and availability
Product Details
Absolute Rotary Encoder - Multiturn
Industrial Line
- Protection class IP67
- ‐40…+85 °C
- Max. 6000 rpm
- DeviceNet™
- Male 2 x M12
- Bus M12 Pin / BUS OUT M12 connector
- Singleturn, 16 bit resolution
- Multiturn, 12 bit resolution
Attributes
| Ambient Temperature | -40…+85 °C |
| Communication Protocol | DeviceNet |
| Customs Tariff Number | 90318080000.0000 |
| Ecl Ss Code V5 1 4 | 27270501 -/- Encoder, absolute |
| Encoder Line | Industrial-Line |
| Housing Material | Powder-coated die-cast aluminium |
| Operating Voltage | 11…25 VDC |
| Output Type | Absolute multiturn |
| Protection Class Housing | IP67 |
| Protection Class Shaft | IP67 |
| Shaft Diameter D Mm | 10 mm |
| Shaft Type | Solid shaft |
| Technology | Optical |
Specifications
| SKU | CS3854568 |
|---|---|
| MPN | RM-89S10S-9B28B-B2M12 |
| Alternate Part # | 1562098 |
