All ProductsTurck

Turck RM-35I12T-5C25B-H1181

SKU: CS3854537MPN: RM-35I12T-5C25B-H1181Alternate Part #: 1545463UPC/EAN: 4047101383867

1545463 - MULTITURN

Turck RM-35I12T-5C25B-H1181
$1,750.76
Unit
Available on backorder
remove
add

Product Details

Absolute Rotary Encoder - Multiturn

Industrial Line

  • Flange with stator coupling, Ø 58 mm
  • Hollow shaft, Ø 12 mm
  • Optical measuring principle
  • Shaft material: stainless steel
  • Protection class IP65 on shaft side
  • -40…+90 °C
  • Max. 6000 rpm
  • 10…30 VDC
  • SSI, Binär
  • M12 connector, 8-pin
  • Singleturn, 13-bit resolution
  • Multiturn, 12-bit resolution

Attributes

Ambient Temperature -40…+90 °C
Communication Protocol SSi
Customs Tariff Number 90318080000.0000
Ecl Ss Code V5 1 4 27270501 -/- Encoder, absolute
Electrical Connection Connector, M12 × 1
Encoder Line Industrial-Line
Flange Diameter Ø  58 mm
Flange Type Flange with stator coupling
Housing Material Die-cast zinc
Operating Voltage 10…30 VDC
Output Type Absolute multiturn
Protection Class Housing IP67
Protection Class Shaft IP65
Shaft Diameter D Mm 12 mm
Shaft Type Hollow shaft
Technology Optical

Specifications

SKUCS3854537
MPNRM-35I12T-5C25B-H1181
Alternate Part #1545463
UPC/EAN4047101383867
